✦Staging & Structures

LPL D8+

Manufacturer
GIS
Model
LPL D8+
Code
GW-PAVTQO
Data status
Level 1 / 3
From open sources

❋ Specs

11
Capacity range
capacity_range_kg
320-1250kg
1
Lifting speed
lifting_speed_m_min
4 / 8 / 8-2m/min
1
Protection Class Ip
protection_class_ip
IP65IP
1
Supply voltage
supply_voltage_v
3x400 / 3x230V
1
Chain safety factor
chain_safety_factor
8:1ratio
1
Weight Lpml250
weight_lpml250_kg
13kg
1
Weight Lpl500
weight_lpl500_kg
23kg
1
Weight Lpl1000
weight_lpl1000_kg
49kg
1
Classification
classification
D8+ (rated for holding loads above people)
1
Chain Type
chain_type
case-hardened galvanised square-profile steel chain
1
Models
models
LPML250 (320 kg) / LPL500 (630 kg) / LPL1000 (1250 kg)
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
