✦Moving Head (Spot/Wash/Beam)

VL1100 LED

Manufacturer
Vari-Lite
Model
VL1100 LED
Code
GW-Y0FYXU
Data status
Level 1 / 3
From open sources

❋ Specs

22
Light source
light_source
Bichromatic LED Light Engine
1
Source Power
source_power_w
445W
1
Max power
max_power_w
650W
1
Input voltage
input_voltage
100-240 VAC, 50/60 Hz
1
Output lumens
output_lumens
11300lm
1
Source Cct K
source_cct_k
3200K
1
CRI (Ra)
cri_ra
92
1
Lens Size
lens_size
165mm
1
Beam angle
beam_angle_deg
19-36, 70 (super zoom mode)deg
1
Color mixing
color_mixing
CMY subtractive (glass wheels), 8-bit, plus digital color enhancement channel
1
Framing Shutters
framing_shutters
4-blade, two-plane, +/-90 rotation
1
Beam Softening
beam_softening
Variable radial frost wheel
1
Dimming
dimming
Electronic 8-bit / 16-bit
1
Strobe Speed
strobe_speed
0-30Hz
1
Cooling
cooling
Hybrid sealed liquid and forced air cooling system
1
Noise
noise_db
35.5 (standard mode, base level 24)dB
1
Pan Angle Deg
pan_angle_deg
540deg
1
Tilt Angle Deg
tilt_angle_deg
270deg
1
Dmx Protocol
dmx_protocol
DMX512-A
1
DMX channels
dmx_channels
16-Bit: 30 (22-iris) ch; Classic: 27 (19-iris) ch
1
Data Connections
data_connections
5-Pin XLR input and thru
1
Power Connection
power_connection
Powercon input
1
