✦Line Arrays

GEO M6

Manufacturer
Nexo
Model
GEO M6
Code
GW-P9YMEI
Data status
Level 1 / 3
From open sources

❋ Specs

16
Configuration
configuration
GEO M620 main + GEO M6B bass extension (2-way passive)
1
Frequency range
frequency_range_hz
80 - 19000Hz
1
Max SPL
max_spl_db
127dB
1
Sensitivity
sensitivity_db
95dB SPL (1W@1m)
1
Drivers
drivers
LF: 1 x 6.5" 8 ohm long-excursion driver; HF: 1 x 1" throat driver on BEA/FEA optimised HR Wavesource
1
Dispersion
dispersion_deg
80 or 120 horizontal x 20 verticaldegrees
1
Crossover frequency
crossover_hz
2000Hz (passive)
1
Nominal impedance
nominal_impedance_ohm
8ohm
1
Power
power_w
450W per box
1
Amplifier
amplifier
NEXO NXAMP powered TDController (up to 12x GEO M6 per NXAMP)
1
Dimensions
dimensions
191 x 373 x 260mm (HxWxD)
1
Weight
weight_kg
9.7kg (GEO M620 net)
1
Weight M6B
weight_m6b_kg
7.6kg (GEO M6B net)
1
Connectors
connectors
2 x NL4 Speakon 4-pole
1
Material
material
Lightweight polyurethane composite
1
Recommended amplifier
recommended_amplifier
NEXO NXAMP4x1MK2 / NXAMP4x4MK2 (powered TDController) or DTDAMP + DTD Controller
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.

❋ Compatibility

Amplifiers
NXAMP4x1mk2GW-VOLAF0NXAMP4x4mk2GW-ELDARVHOLOPLOT ControllerGW-M8ZJUFDTDGW-TOPJWO

NEXO NXAMP4x1MK2 / NXAMP4x4MK2 (powered TDController) or DTDAMP + DTD Controller
