✦Line Arrays

W8LC

Manufacturer
Martin Audio
Model
W8LC
Code
GW-WJM9SP
Data status
Level 1 / 3
From open sources
No photo yet

❋ Specs

10
Frequency range
frequency_range_hz
60-18000Hz
1
Drivers
drivers
12" LF (Hybrid, рупор), 2 x 6.5" MF, 3 x 1" HF компрессионных
1
Power
power_w
400/200/100 (LF/MF/HF, AES)W
1
Sensitivity
sensitivity_db
103/106/109 (LF/MF/HF)dB
1
Max SPL
max_spl_db
135 (пик)dB
1
Nominal impedance
nominal_impedance_ohm
8Ω
1
Horizontal coverage
horizontal_coverage_deg
90°
1
Connectors
connectors
2 x Neutrik NL8
1
Dimensions
dimensions_mm
1000 x 367 x 550
1
Weight
weight_kg
58kg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
