✦Power Amplifiers

PLM 20K44

Manufacturer
Lab.gruppen
Model
PLM 20K44
Code
GW-GBLA07
Data status
Level 1 / 3
From open sources

❋ Specs

29
Power Rating
power_rating_w
20000
1
DMX channels
dmx_channels
4
1
Width
width_mm
483
1
Height
height_mm
88
1
Depth
depth_mm
424
1
Depth With Support
depth_with_support_mm
498
1
Weight
weight_kg
17
1
Rack units
rack_units
2U
1
Analog Inputs
analog_inputs
4 channels Iso-Float
1
Aes3 Inputs
aes3_inputs
4 channels
1
Dante Inputs
dante_inputs
8 channels dual redundancy
1
Breaker Emulation Limiter
breaker_emulation_limiter_a
32
1
Internal Processor
internal_processor
Lake Processor with MESA EQ asymmetric filters
1
Network Standard
network_standard
AES67
1
Connectors
connectors
SpeakON (SP) or binding posts (BP)
1
Channels
channels
4
1
Dimensions
dimensions_mm
483x88x424mm
1
Frequency range
frequency_range_hz
20-20000Hz
1
Impedance
impedance_ohm
2-16 (+70V/100V HiZ)Ω
1
Inputs
inputs
4x XLR analog (Iso-Float) + 2x XLR AES3
1
Outputs
outputs
speakON (1xNLT8+2xNLT4) or 4x binding post
1
Power
power_w
20000W
1
Signal-to-noise ratio
signal_to_noise_db
>114dBA
1
THD
thd
<0.05%
1
Type
type
4-channel power amplifier with Lake processor and Dante
1
Power per channel
power_per_channel_w
4600 @ 4 ohm / 2300 @ 8 ohm (single ch burst)W
1
Dimensions
dimensions
483 x 88 x 463 (2U)mm
1
DSP
dsp
Lake processor, up to 4 modules: FIR crossover, EQ, delay, LimiterMax
1
Networking
networking
8x8 Dante I/O, 2 x AES3 (4 channels), 4 analog inputs
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
