✦Point Source / Full-Range

SRX738

Manufacturer
JBL Professional
Model
SRX738
Code
GW-RIWC6C
Data status
Level 1 / 3
From open sources

❋ Specs

12
Dispersion
dispersion_deg
60x40°
1
Drivers
drivers
18" Differential Drive LF, CMCD cone midrange compression driver
1
Configuration
configuration
3-way, bi-amp or passive full range
1
Frequency range
frequency_range_hz
35-20000Hz
1
Max SPL
max_spl_db
130dB
1
Sensitivity
sensitivity_db
95dB
1
Nominal impedance
nominal_impedance_ohm
8Ω
1
RMS power
power_rms_w
800W
1
Peak power
power_peak_w
3200W
1
Connectors
connectors
2 x Neutrik Speakon NL-4
1
Dimensions
dimensions_mm
1022 x 534 x 508mm
1
Weight
weight_kg
43kg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
