✦Line Arrays

MYRA 214L

Manufacturer
FBT
Model
code 44495
Code
GW-JL1KDU
Data status
Level 1 / 3
From open sources

❋ Specs

17
Frequency range
frequency_range_hz
40-20000Hz
1
Max SPL
max_spl_db
147dB
1
LF power
power_lf_w
1600W
1
Power Midhf
power_midhf_w
640W
1
LF transducer
lf_transducer
2 x 14" neodymium - 3" coil
1
Midhf Transducer
midhf_transducer
2 x coaxial 4"VC mid + 2.5"VC HF, 1.4" throat (B&C)
1
Configuration
configuration
3-way bi-amped passive
1
Dispersion
dispersion_deg
90 horizontal, splay 0.25-8deg
1
Connectors
connectors
Neutrik NLT4
1
Enclosure
enclosure
Baltic birch + polyurea coating
1
Drivers
drivers
2 x 14" neodymium woofers (3" VC) + 2 x coaxial compression drivers (4" MF / 2.5" HF VC, 1.4" throat, B&C)
1
Power
power_w
800 LF / 300 MF-HF (continuous), 1600 / 600 programW
1
Peak power
power_peak_w
3200 LF / 1200 MF-HFW
1
Impedance
impedance_ohm
4 LF / 16 MF-HFohm
1
Weight
weight_kg
61.5kg
1
Dimensions
dimensions
930 x 398 x 530 (H x W x D)mm
1
Cabinet material
cabinet_material
Baltic birch plywood with polyurea coating
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
