✦Point Source / Full-Range

Madras M212

Manufacturer
Dynacord
Model
Madras M212
Code
GW-TKYEVI
Data status
Level 1 / 3
From open sources
No photo yet

❋ Specs

11
Power
power_w
600 (460 + 140)W
1
Max SPL
max_spl_db
131dB
1
Frequency range
frequency_range_hz
50-19000Hz
1
Dispersion
dispersion_deg
80 x 55°
1
Dimensions
dimensions_mm
430 x 800 x 432mm
1
Weight
weight_kg
42kg
1
Drivers
drivers
2 x Electro-Voice ND12A + ND6-16
1
Sensitivity
sensitivity_db
103dB
1
Inputs
inputs
XLR balanced, 20 kOhm
1
Connectors
connectors
XLR in/thru, PowerCon mains in/out
1
Amplifier
amplifier
Class H, 460 W LF + 140 W HF
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
