✦Moving Head (Spot/Wash/Beam)

Diablo-S

Manufacturer
Ayrton
Model
011340
Code
GW-FIYQRS
Data status
Level 1 / 3
From open sources

❋ Specs

25
Configuration
configuration
LED profile moving head
1
Power
power_w
300W
1
Max power consumption
max_power_consumption_w
550W
1
Light source
light_source
LED Mono Block, sealed, white
1
Luminous output
luminous_output_lm
19413lm
1
CCT
cct_k
8000K
1
CRI (Ra)
cri_ra
70Ra
1
Led Engine Life L70 H
led_engine_life_l70_h
40000h
1
Zoom range
zoom_range_deg
7-53deg
1
Zoom ratio
zoom_ratio
7.5:1
1
Lens Size
lens_size_mm
119mm
1
Framing
framing
4 blade
1
Framing Rotation Deg
framing_rotation_deg
+/-45deg
1
Iris
iris
15 blade, 15% to 100%
1
Color system
color_system
CMY, CTO and 7-color wheel
1
Gobos
gobos
7 rotating glass gobos + 1 open
1
Gobo Diameter
gobo_diameter_mm
25.5mm
1
Pan range
pan_range_deg
540/630deg
1
Tilt range
tilt_range_deg
263deg
1
DMX control
dmx_control
DMX (USITT DMX-512-A), RDM (ANSI/ESTA E1.20)
1
Wireless Dmx
wireless_dmx
CRMX TiMo RDM receiver
1
Connector
connector
powerCON True1 TOP
1
Cooling System
cooling_system
Advanced Liquid Cooling
1
Dimensions
dimensions
365 x 591 x 212mm
1
Weight
weight_kg
22kg
1

Every field carries its own trust-tier: core data is confirmed by the manufacturer, peripheral data — by AI (with a source link). Safety-critical parameters (load ratings) are never published below vendor-claimed — a liability requirement.
